Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers

Name: Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers
Brand: Spectra Precision
SKU: UL633N
Price: 4080.00 USD
Availability: InStock

SKU# UL633N

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 0

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 1

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 2

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 3

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 4

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 5

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 6

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 7

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 8

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 9

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 10

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 11

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 12

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 13

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 14

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 15

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers, large image number 16

+ 12 more

Made In USA

Acme Tools Guarantee

Qty

(Max. order of 1,000)

Secure Checkout

Product Details

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers

Spectra Precision

Please follow our Community Guidelines and be kind!

Description

Spectra Precision Universal Laser with RC603N Remote & Two HL760 Laserometer Receivers

The Spectra Precision UL633N Universal Laser is the only construction laser that provides the ability to control level, alignment, single/dual grade and vertical - allowing you to do more work with one tool. The Spot Finder offers additional versatility for 90-degree layout applications on concrete pads as well as indoors for wall layout. The UL633N comes with two HL760 advanced digital readout receivers and the SF601 SpotFinder! Talk about additional power in your job, this has it all.

California Proposition 65 Warning.

Features

Multiple Applications - the UL633N Universal Laser is the only construction laser that provides the ability to control level, alignment, single/dual grade and even do grade in vertical allowing you to do more work with one tool

Automatic Self-Leveling - provides fast, easy set-up for horizontal level, grade or vertical alignment

Automatic Grade Matching - meaning the laser moves to the on-grade position on the receiver automatically by communicating wirelessly with the receiver and the grade is then calculated - this is generally used when a constant fall is desired but the grade may not be known (renewing existing driveways or matching existing surfaces)

Grade Range - large, fully compensated grade range from -25% to 25% - keeping the laser levelled no matter what grade you need reducing errors and improving productivity

Includes - two HL760 advanced digital readout receivers and the SF601 SpotFinder

Anti-Vibration Filter -a laser can be affected by high vibration or strong wind, especially when the laser is mounted on a tall tripod -the UL633N has an anti-vibration filter that can be set according to the conditions allowing work to continue regardless of wind conditions or excessive vibrations

Rugged - Designed to operate on the toughest of jobsites, the UL633N can withstand a 1m (3 ft) drop directly onto concrete or 1.5m (5 ft) pushover on tripod, eliminating costly repairs

Planelok - The PlaneLok function can be activated, keeping the laser beam fixed to a receiver in a set a position eliminating any error that can be caused by fluctuating temperatures, keeping the laser accurate and error free

Automatic Axis Alignment - A critical factor when working with grade is alignment to the grade hub. If an alignment is off, error can be introduced and exaggerated. The UL633N has an Automatic Axis Alignment function, allowing the user to set-up simply and quickly, maintaining accuracy and eliminating costly errors. The Automatic Axis Alignment function has the added benefit of being able to simultaneously align on two axes not at 90 degrees to each other. This is especially useful when trying to construct envelope set-ups on a concrete pad or when setting a dual grade for a drainage channel intersecting another channel at an angle not at 90 degrees to the main run

Mask Mode - The UL633N has a virtual masking function that allows the laser beam to be turned off in up to 3 sides, avoiding false reading from glass reflections or interfering with other lasers on the same jobsite

Specifications

Brand Name

Spectra Precision

Assembled Weight (lbs)

6.8

Country of Origin

United States

MFG Part # (OEM)

UL633N

Package Contents

UL633N Universal Laser, RC603N Remote Control, (2) each HL760 Laserometer Receivers, (2) each Clamps C70 for Receiver, Spot Finder SF601 with Sun Shield, Spot Finder adapter with Rubber Strap, Worldwide Charger, Rechargeable NiMH Battery Pack - Q104667, Carrying Case, Operating Manual
