Spectra Precision Dual Grade Laser with HL760 Laser Receiver

Name: Spectra Precision Dual Grade Laser with HL760 Laser Receiver
Brand: Spectra Precision
SKU: GL622N
Price: 3032.99 USD
Availability: InStock

SKU# GL622N

Spectra Precision Dual Grade Laser with HL760 Laser Receiver, large image number 0

Spectra Precision Dual Grade Laser with HL760 Laser Receiver, large image number 1

Spectra Precision Dual Grade Laser with HL760 Laser Receiver, large image number 2

Spectra Precision Dual Grade Laser with HL760 Laser Receiver, large image number 3

Made In USA

Acme Tools Guarantee

Qty

(Max. order of 1,000)

Secure Checkout

Product Details

Spectra Precision Dual Grade Laser with HL760 Laser Receiver

Spectra Precision

Please follow our Community Guidelines and be kind!

Description

Spectra Precision Dual Grade Laser with HL760 Laser Receiver

Spectra Precision® GL622N/GL622IR Grade Lasers. Easy-To-Use, Full Featured Automatic Grade Lasers. The GL622N Dual Grade Laser is rugged, automatic self-levelling laser with grade capability from -25% to + 25% and can be used for a wide variety of grade, excavating and alignment applications by general and specialty contractors.

California Proposition 65 Warning.

Features

Multiple Applications - the Spectra Precision GL622N provides the ability to control level, alignment, dual grade and set 90 degrees. The GL622IR is not used for vertical alignment or 90 degree layout

Long Range - one person elevation and grade control with 800 m (2,600 ft) diameter range increases productivity. Automatic self-levelling - provides fast, easy set-up for horizontal level, grade or vertical alignment (vertical on GL622N only)

Automatic Grade Matching - meaning the laser moves to the on-grade position on the receiver automatically by communicating wirelessly with the receiver and the grade is then calculated - this is generally used when a constant fall is desired but the grade may not be known (renewing existing driveways or matching existing surfaces)

Grade Range - Large, fully compensated grade range from -25% to 25% - keeping the laser levelled no matter what grade you need reducing errors and improving productivity

Anti-Vibration Filter - A laser can be affected high vibration or strong wind, especially when the laser is mounted on a tall tripod -both the GL612N, GL622IR, and G622N have an anti-vibration filter that can be set according to the conditions allowing work to continue regardless of wind conditions or excessive vibrations

Rugged - the GL622N and GL622IR can withstand a 1m (3 feet) drop directly onto concrete or 1.5m (5 feet) pushover on tripod, eliminating costly repairs.

PlaneLok - The PlaneLok function can be activated, keeping the laser beam fixed to a receiver in a set a position eliminating any error that can be caused by fluctuating temperatures, keeping the laser accurate and error free.

Automatic Axis Alignment - A critical factor when working with grade is alignment to the grade hub. If an alignment is off, error can be introduced and exaggerated. The GL622N has an Automatic Axis Alignment function, allowing the user to set-up simply and quickly, maintaining accuracy and eliminating costly errors.

Mask Mode - the lasers have a virtual masking function that allows the laser beam to be turned off in up to 3 sides, avoiding false reading from glass reflections or interfering with other lasers on the same jobsite.

GL622IR Model - This model features an invisible infrared laser beam and is a Class 1 laser, the safest laser classification possible. This type of beam is required in special applications where a visible beam is a safety hazard, distracting or otherwise is not permissible.

Specifications

Brand Name

Spectra Precision

Assembled Weight (lbs)

6.8

Country of Origin

United States

MFG Part # (OEM)

GL622N

Package Contents

GL622N Grade Laser, HL760 Laser Receiver, C70 Adapter, 105516 Vertical Adapter for HL Receiver, RC602N Radio Remote Control, Q104234 NiMH Rechargeable Batteries, Worldwide Charger, Hard Case
