JET 14 x 40 Electronic Variable Speed Lathe

SKU# JT9-311448
4.7 out of 5 Customer Rating
JET 14 x 40 Electronic Variable Speed Lathe, large image number 0
JET 14 x 40 Electronic Variable Speed Lathe, large image number 1
JET 14 x 40 Electronic Variable Speed Lathe, large image number 2
JET 14 x 40 Electronic Variable Speed Lathe, large image number 3
JET 14 x 40 Electronic Variable Speed Lathe, large image number 4
JET 14 x 40 Electronic Variable Speed Lathe, large image number 5
JET 14 x 40 Electronic Variable Speed Lathe, large image number 6
JET 14 x 40 Electronic Variable Speed Lathe, large image number 7
JET 14 x 40 Electronic Variable Speed Lathe, large image number 8
Previous Next
+ 4 more
See Price in Cart
Discounted Price Shown in Cart
See Price in Cart
Discounted Price Shown in Cart
Sale:
Was:
Out of Stock
Delivery to -
- Est. Arrival - Est. Ship - Est. Arrival - Get it as soon as {0} Edit location Add Zip Code
Pick Up at
Store Address -
Available within 4 hours
Contact Store:
Est. Email Delivery: within 24 hours
Made In USA
  No Air Shipments

  Free Freight  Shipping  (Truck freight shipping to lower 48)
JET 14 x 40 Electronic Variable Speed Lathe
See Price in Cart
Discounted Price Shown in Cart
See Price in Cart
Discounted Price Shown in Cart
Sale:
Was:
Out of Stock
Qty
Secure Checkout
Affirm
Pay over time
with Affirm on orders below $17,500

Product Details

JET 14 x 40 Electronic Variable Speed Lathe
JET

Please follow our Community Guidelines and be kind!

Description

JET 14 x 40 Electronic Variable Speed Lathe

The EVS-1440B is engineered to maximize your shop’s output. The D1 4 spindle is precision ground for accuracy and supported by class 7 tapered roller bearings capable of a run out maximum of .0004 In.. the 2 speed gearbox allows operators to easily work at low speeds from 40 to 365 RPM and at high speeds from 220 to 2,000 RPM's.

California Proposition 65 Warning.
View Warning Label

Features

V-way bed design is induction hardened and ground
Splined, not keyed, shafts are utilized
D1-4 spindle is precision ground for accuracy and supported by high quality tapered roller bearings
Independent lead screw and feed rod
Adjustable gibs are incorporated in the carriage and slide ways
Class 7 precision taper roller bearings keep spindle run out to a maximum of 0.0004"
Meehanite castings retain their tolerance and remain rigid through many years of machining
14 x 40 Electronic Variable Speed Lathe with Newall DP700 DRO, 3 HP, 230/460 V, 3Ph
Emergency stop within easy reach of the operator
Electronic chuck key docking station

Specifications

Brand Name
JET
Assembled Weight (lbs)
1320
California Proposition 65 Warning Required
Yes
Center To Center (in)
40
Color
Gray
Country of Origin
Taiwan
ETL Listed
No
Height (in)
50
Horsepower (hp)
3
Length
68.5 in

MFG Part # (OEM)
JT9-311448

Maximum Speed (rpm)
1800
Net Tool Weight (lbs)
1320
Package Contents
14 x 40 Electronic Variable Speed Lathe

Product Condition
New

UL Listed
No

UPC
731325792010

Variable Speed
Yes
Voltage
230/460 Volts
Warranty Type
2 Years Limited
Weight (lbs)
1584
