Product Details

Campbell Hausfeld 30 Gallon 3 in 1 Compressor/Generator/Welder

Description

Campbell Hausfeld 30 Gallon 3 in 1 Compressor/Generator/Welder

The Campbell Hausfeld 3-in-1 air compressor/generator/welder (GR3200) is ideal for jobsites and work trucks. Designed for high output and industrial reliability, its two-stage, cast-iron air compressor fills a 30-gallon air tank with a product life of 15,000 hours (based on B-10 bearing rating). A robust generator provides 5,000 continuous watts of 120V and 240V AC power to operate most electric tools and lights, and a DC welder delivers a maximum 200 amps of power to weld up to 1/2-inch thick steel. Powering it all is a Honda GX-390 engine that is engineered to deliver a long operating life of economical, reliable performance. A heavy-duty, 14-gauge steel belt guard is securely bolted to the unit, but can be quickly removed to provide access to routine maintenance items.

View Warning Label

Features

Two stage, cast iron air compressor for high output and industrial reliability
Both 120V and 240V electrical outlets
5,000 Watt generator complete with U/L and OSHA compliant panel
Powerful GX-390 Honda engine provides reliable and mighty power capabilities
Up to 1/2 inch welding--welds 16 gauge to 1/2 in. steel
Compressor maximum pressure: 175 PSI
Delivers air flow of 14 SCFM @ 90 PSI, 13.6 SCFM @ 100 PSI, and 13.3 SCRM @ 175 PSI
Welder Amps: 50-200 Amp DC
Duty Cycle: 100% @ 150 A, 65% @ 180 A

Specifications

Brand Name
Campbell Hausfeld
Air Compressor Pump Design
Oil Lubricated
Air Volume (CFM)
14 SCFM @ 90 PSI; 13.7 SCFM @ 175 PSI
Amperage (A)
200
Application
Air Brushing, Blow Cleaning, Bolting, Brad Nailing, Finish Nailing, Framing Nailing, Inflation, Grinding, Sanding, Spraying, Stapling, Tightening, Welding, Generator
Assembled Weight (lbs)
591
California Proposition 65 Warning Required
Yes
Color
Black
Compressor Design
Horizontal (Stationary)
Country of Origin
United States
CSA Certified
No
Decibel Rating (dB)
92
ETL Listed
No
Fuel Type
Gas
Height (in)
48
Horsepower (hp)
13.00

MFG Part # (OEM)
GR3200

Maximum Air Pressure (psi)
175
Maximum Pressure Rating (psi)
175
Operating Position
Horizontal
Package Contents
Compressor/Generator/Welder unit, manual
Pressure Rating (psi)
175

Product Condition
New

Start Type
Pull
Tank Capacity (gal)
30
Tank Configuration
Single
Tank Material
Steel
Tank Pressure Gauge
Yes
UL Listed
Yes

UPC
045564637637

Voltage
120/240
Warranty Type
3 Years Limited
Weight (lbs)
591
Wheeled
No
