Bosch 2.3 HP Electronic Modular Router System

Bosch

Please follow our Community Guidelines and be kind!

Description

Bosch 2.3 HP Electronic Modular Router System

The Bosch MRC23EVSK 2.3 HP Electronic Modular Router System is an advanced set-up that provides a fixed base and a plunge base for the MR23EVS router. This system allows for outstanding operator control, with the trigger-control system that has a power switch in both the plunge-base's and the fixed-base's handle. The plunge base's Afterlock microfine bit-depth adjustment at any plunge setting allows for precision, with an adjustable turret stop makes it easy to set any cumulative depth. With a smooth plunge action and a spring-lock plunge lever, this router gets accurate results. The fixed base has microfine bit-depth adjustment, with a continuous depth range of 1-5/8 in., allowing for accurate and fast changes, while its precision-centering design allows the bit to be centered with the sub-base or optional template guides. The router has a 15 Amp motor and adjustable speed settings. The variable-speed dial allows the operator to match the speed to the material. Constant Response circuitry delivers a constant speed throughout the cut. Users can glide along the intended cutline using dovetail fixtures, templates, jigs and other guidance devices.

California Proposition 65 Warning.

Manuals

Use and Care Manual - PDF

Warranty - PDF

Specification - PDF

Instructions / Assembly - PDF

Features

Trigger-control system – trigger power switch located in handle for enhanced control

Powerful 15 Amp motor – produces 10,000 to 25,000 RPM and 2.3 hp

Precision-centering design – makes it easy to keep bit on cut line

Afterlock plunge-base depth adjustment – easy, precise adjustments at any plunge setting

Versatile fixed-base depth adjustment – features 1-5/8 In. continuous microfine adjustment range

Above-table depth adjustment when fixed base is installed in router table

Constant Response circuitry – maintains constant speed under load

Soft-start function – reduces start-up torque

Always-on LED lighting – for enhanced visibility in bit area

Two-stage quick clamp system – for fast tool-free conversion

Specifications

Brand Name

Bosch

Amperage (A)

Assembled Depth (in)

6.75

Assembled Weight (lbs)

12.6

Assembled Width (in)

12.6

California Proposition 65 Warning Required

Color

Blue

Country of Origin

Mexico

CSA Certified

Depth Adjustment

Yes

Dust Collection

Electronic Speed Control

Yes

ETL Listed

Handle Type

Side Handles

Height (in)

9.5"

Horsepower (hp)

2.3

Length

120 in

Lock-on Switch

Yes

MFG Part # (OEM)

MRC23EVSK

Maximum RPM

25000

Net Tool Weight (lbs)

12.6

Package Contents

Motor, Fixed Base (MRF01), Plunge base (MRP01), 1/4" Self-Releasing Collet Chuck - 2 610 906 283, 1/2" Self-Releasing Collet Chuck - 2 610 906 284, 16mm Shaft Wrench - 2 610 991 388, 24mm Collet Nut Wrench - 2 610 992 417, T-Handle Hex Height Adjustment Wrench - 2610923193, Carrying Case - 2 610 004 484, Pack of 3 M4 Screws for table mounting - 2610005966
