Baileigh RDB-050 Rotary Draw Bender Manual

Name: Baileigh RDB-050 Rotary Draw Bender Manual
Brand: Baileigh
SKU: 1006768
Price: 2309.00 USD
Availability: InStock

SKU# BA9-1006768

Baileigh RDB-050 Rotary Draw Bender Manual, large image number 0

Baileigh RDB-050 Rotary Draw Bender Manual, large image number 1

Baileigh RDB-050 Rotary Draw Bender Manual, large image number 2

Baileigh RDB-050 Rotary Draw Bender Manual, large image number 3

Baileigh RDB-050 Rotary Draw Bender Manual, large image number 4

Baileigh RDB-050 Rotary Draw Bender Manual, large image number 5

Baileigh RDB-050 Rotary Draw Bender Manual, large image number 6

Baileigh RDB-050 Rotary Draw Bender Manual, large image number 7

+ 4 more

Acme Tools Guarantee

Qty

(Max. order of 1,000)

Secure Checkout

Product Details

Baileigh RDB-050 Rotary Draw Bender Manual

Baileigh

Please follow our Community Guidelines and be kind!

Description

Baileigh RDB-050 Rotary Draw Bender Manual

Need an affordable but powerful bender with enough capacity for almost about any chassis fabrication shop? Baileigh’s patented RDB-050 manual tube bender is revolutionary in function, capacity, and efficiency.

California Proposition 65 Warning.

Features

Tackles up to 2.5 In. OD mild steel with a wall thickness of 0.12 In. and 2 In. OD chrome moly with a wall thickness of 0.12 In.

Speed 1 produces 4 Deg per pull, This speed has the most torque, suitable for bending 2 In. OD chrome moly or 2.5 In. OD mild steel

Speed 2 produces 8 Deg per pull for intermediate materials

Speed 3 produces 12 Deg per pull for lighter gauge materials

Bends up to 200 Deg in one shot without you needing to stop and reset the machine

Anti-spring back mechanism holds each bend in place as the operator ratchets forward

No assembly or disassembly needed to produce a bend

All pivot points use aluminum bronze bushings and thrust washers for long machine life

Quick-release hook arm inserts assist when you’re changing over the machine to a different size of tubing, You can do a complete changeover in 1 minute or less

Just walk up to the machine, put your tubing into the hook arm insert, and begin bending, When the bend is complete, return the machine to the home position, pull your bend out-and you’re all set, tooling not included
