Baileigh BP-3360NC 66 Inch 33 Ton Hydraulic Press Brake
Baileigh

Please follow our Community Guidelines and be kind!

Description

Baileigh BP-3360NC 66 Inch 33 Ton Hydraulic Press Brake

The Baileigh BP-3360NC 66 Inch 33 Ton Hydraulic Press Brake combines a 66-inch working width with encoder-controlled positioning and a heavy-duty welded steel structure for consistent sheet metal bending. Three operating modes provide flexibility for setup, manual control, and production, while two hydraulic cylinders move the top beam and digital readouts display stroke and back gauge positions. A motorized back gauge, foot pedal control, bend-delay timer, and parallel beam mechanism help simplify repeatable bending across the machine's width. The 3,300-pound construction supports the hydraulic pressure during operation, while the hardened stabilizing track and three axes of bearings help maintain alignment between the dies. The machine includes hardened single-Vee American tooling, front material rests, and a 6-light safety curtain. It also comes with a 1-year parts warranty and lifetime phone technical support.

California Proposition 65 Warning.

Features

Runs in jog, manual, and automatic modes for setup, controlled operation, and full production
Uses 2 encoder-controlled hydraulic cylinders to move the top beam with precision
Displays downward stroke position on a digital readout for fine-tuned bend depth
Allows quick adjustment of top beam pressure and stroke position for different travel requirements
Provides a programmable bend-delay timer to hold the beam at the bottom of the stroke
Uses 2 hand wheels to adjust beam and back gauge positions across the full 66-inch width
Includes a foot pedal for raising and lowering the stroke while keeping both hands free to position material
Uses a motorized back gauge with a solid ball screw trolley mechanism and dedicated encoder DRO
Employs a parallel beam mechanism to synchronize the top and bottom dies for consistent bends across the machine
Features a heavy electro-welded steel frame and 3,300-pound construction for rigidity during production

Specifications

Brand Name
Baileigh
Assembled Weight (lbs)
5450
Country of Origin
Taiwan

MFG Part # (OEM)
1000803

Package Contents
(1) Hydraulic Press Brake

Product Condition
New

Restrictions
CA Prop 65

UPC
731325394436

Warranty Type
1 Year Limited
