Maksiwa International Sliding Panel Saw 220V 1 Phase 5HP

Item No. SKU# BMS.1600.IR
4.3 out of 5 Customer Rating
  • Available to Order
$5,845.00
Delivery to -
43215
- Est. Arrival Sun May 12 - Sun May 19 Edit location
  Free Shipping (Ground shipping to lower 48)
Acme Tools Guarantee
Maksiwa International Sliding Panel Saw 220V 1 Phase 5HP
$5,845.00
Qty
Secure Checkout

Description

Maksiwa International Sliding Panel Saw 220V 1 Phase 5HP

Introducing the New BMS.1600.IR. The BMS series is one of Maksiwa’s top seller sliders that has been completely redesigned from the ground up with improved construction and materials. The new design is more ergonomic and features a more powerful 1HP scoring motor, Digital Rip Fence Readout, adjustable leveling feet, dual blade covers, two flip stops, integrated dust collection exhaust on a swing-away arm, and new soft touch buttons and control panel. If you have limited space on your shop but is looking for a powerful slider, the new BMS.1600.IR is your choice! This machine boasts a robust 5HP main motor, available in 1 Phase 220V. The anodized aluminum sliding table is designed to ensure durability and longevity, while the European-style 41″ rip fence, built with heavy-duty casting, glides smoothly on a micro-polished solid steel bar. Finding precise measurements is made easy with the included micro-adjustment feature, adding convenience and efficiency to your work. As a testament to our commitment to quality, we offer a comprehensive 2-year warranty on all parts and service, providing you with peace of mind.

Features

Main Motor: 5 HP 4000 RPM 3.7 Kw, Electrical Specs: 1 PH 220V 30 Amps 60Hzs
Max Blade Diameter: 12" | 305mm
Main Blade Arbor: 30mm
Main Blade Max Cutting Height at 90º: 3 ½”
Main Blade Max Cutting Height at 45º:2 ½”
Scoring Motor: 1HP, Scoring Motor Blade: 4 ¾” | 120mm, Scoring Blade Arbor: ¾”
Sliding Table Dimension: 63" x 14", Main Table with Supporting Table: 31.5" x 40", Crosscut fence max. Collapsed/Extended: 50" / 85"
Machine Dimension Collapsed: (LxWxH) 66" x 98" x 42", Rip Fence Bar Solid Steel Micro Polished: 1”, Max Tilt: 45º, Max Cutting Length: 62", Dust Collection Port: 4”,

Specifications

Brand Name
Maksiwa International
Amperage (A)
24
Assembled Weight (lbs)
805
Base Width (in)
66
Color
Multiple
Country of Origin
Brazil
Diameter
12 in
Dust Port Outside Diameter (in)
2
Horsepower (hp)
5
MFG Part # (OEM)
BMS.1600.IR
Maximum Cutting Depth (in)
3
Package Contents
1 Phase 5HP Sliding Panel Saw,1 Dust Port
Package Depth
40
Package Height
35
Package Weight
945
Phase
Single Phase
Product Condition
New
UPC
7898531013391
Wheeled
No
