Versatile: Parallel cuts up to 280 mm; cross cut width of up to 450 mm. Angled cuts from -2 to 47 deg
Practical: At a cutting height of up to 35 mm, through to angled cuts right down to -10 deg, ideal for undercutting infill panels
Compact and mobile: Can be transported with one hand in the practical Systainer format. Even lighter with the UG-CSC-SYS underframe
Extreme precision: The height and angle are electrically adjusted at the press of a button via the digital display - accurate to within a tenth of a millimeter
Reproduce cuts easily: The height and angle (mm and inches) are set parallax-free via the digital display, i.e. more accurately than any visual judgement. Reproducible cuts are ensured
Convenient: Four saw blade positions can be saved and selected via the digital display
Highly precise parallel side fence: Robust parallel side fence with double clamp (via just one clamp lever) for exact alignment and perfect cutting results
Highly precise angle stop: The angle stop is optimally aligned and centrally clamped via a groove on the slide. For miter angles between -70 and +70 deg
Absolutely judder-free: Ball bearing-mounted slide for parallel and angled cuts with maximum precision
Powerful: The brushless EC-TEC motor with high speeds of 6800 rpm guarantees fast sawing progress and perfect cutting results
Brand Name
Festool
Assembled Weight (lbs)
51.81
Country of Origin
China
MFG Part # (OEM)
577383
Package Contents
Chip Collection Sack, Hex Key, WAF 6, Parallel Side Fence, Preset Profile, Setting Rail, Splitting Wedge for Concealed Cuts, Splitting Wedge with Protective Hood, Wood Fine Cut HW 168 x 1.8 x 20 WD42 Circular Saw Blade, Workpiece Holder, UG-CSC-SYS Underframe, SYS 18V 2 x 5.0/TCL 6 Duo Energy Set, UG-CSC-SYS Underframe
Package Depth
26
Package Height
18
Package Weight
55
Product Condition
New
Size
512 mm Length x 396 mm Width x 296 mm Height
